技术 - Article 2024.05.22

Application Guide > Automotive > BMS (Battery Management System)

为了缩短电动车的充电时间及保证行驶距离，电池持续扩大高电压化，且要求高电压化的安全性。

因此电池管理系统(BMS, Battery Management System) 内用来处理高压电池线噪音的高压MLCC也在增加。



三星电机为了满足市场需求，正持续扩大高压MLCC line-up及供应。


회로이미지 1.png


MLCC 趋势 : 高电压

▷ 高频降噪

▷ 高可靠性

 → 推荐方案 : X7* PN Series



Size

(inch/mm)

Rated Voltage

[Vdc]

TCC

Capacitance

Part Number

MP

Status

Sample

Availability

1206/3216

2000

X7R

2.2nF

CL31B222KJHRPN#

NEW

Available

1206/3216

2000

X7R

1nF

CL31B102KJHRPN#

NEW

Available

1206/3216

1000

X7R

22nF

CL31B223KIHRPN#

NEW

Available

1206/3216

1000

X7R

10nF

CL31B103KIHXPN#

In MP

Available

1206/3216

1000

X7R

2.2nF

CL31B222KIFXPN#

In MP

Available

1206/3216

630

X7R

33nF

CL31B333KHH6PN#

In MP

Available

1210/3225

630

X7R

100nF

CL32B104KHU6PN#

In MP

Available
