Automotive

无人驾驶汽车不仅是出行手段的变化,也在众多领域给我们的生活带来了变化。无人驾驶汽车为不会开车或是开不好车的人们提供了便利的出行手段。将在路上开车消耗的时间还给驾驶的人们,并非私有,而是共有的共享经济得以扩散。

无人驾驶汽车即将带来的充满魅力的生活变化,其中心就在三星电机。

Automotive Core Technology with High Reliability

三星电机的高品质车载用 MLCC为车辆内电子控制系统的稳定动作提供支持。

三星电机通过提供高性能、高可靠性产品,在车载用被动元件领域发挥全球领先作用。

MLCC
MLCC
三星电机为安全、咨询娱乐等多种应用程序提供多样的车载用 MLCC。这种 MLCC具备出色的电特性,为其高可靠性提供保障。同时通过柔性外部电极(Soft Termination)技术,吸收外部物理压力,防止发生短路。
  • xEV
  • ADAS & Safety
  • Body & Chassis
  • Infotainment & Comfort

Samsung Electro-Mechanics’
MLCC Enabling Automotive

ADAS

  1. ADAS,SCC(Radar), Smart Cruise Control.

    LV Battery → LV Power Supply → Low Voltage
    ↔ User Interface & Communication ↔ MCU → Waveform Generator → 76/77 GHz Transmitter → Tx#1~2 → Wave → Targets
    ↔ User Interface & Communication ↔ MCU ↔ ADC#1 ← 76/77 GHz Receiver#1 ← Rx#1~4 ← Wave → Targets
    ↔ User Interface & Communication ↔ MCU ↔ ADC#2 ← 76/77 GHz Receiver#2 ← Rx#5~8 ← Wave → Targets

    放大此图片
  2. ADAS, NVS (Infrared), Night Vision System

    LV Battery → LV Power Supply → Low Voltage
    Targets → IR → Lens → Infrared Sensor(*Microbolometer) ↔ FPGA ↔ GMSL ↔ Image Signal Processing → Display(*Cluster,*HUD)
    Shutter Driver ← FPGA ↔ Memory(*SDRAM, *FLASH, *EEPROM)

    放大此图片
  3. ADAS, LiDAR, Light Detection And Ranging

    LV Battery → High-Side Switch → PTC Heater
    LV Battery → LV Power → Supply → Low Voltage
    ↔ User Interface & Communication ↔ MCU ↔ Motor → for Beam Steering → Mirror → Targets
    ↔ User Interface & Communication ↔ MCU ↔ SoC → Light Source(Laser Diode → Collimating Lens), LV Bat. //→ Mirror → Emitting → Targets
    ↔ User Interface & Communication ↔ MCU ↔ SoC ← Light Detector(AMP ← APD Array ← Condenser Lens), LV Bat. ←// Mirror ← Reflection ← Targets

    放大此图片

IVI

  1. IVI, Head Unit, for Audio-Video-Navigation

    LV Battery → LDO & Switch → LV Power Supply → Low Voltage
    LV Battery → LDO & Switch → Camera (Rear), Mike (for Hands-Free), Bluetooth, Integrated Antenna (GPS/DMB), Radio, Control Button (Volume) → Transceiver ↔ Multimedia Core ↔ Memory (Flash & RAM)
    Multimedia Core ↔ Monitor (Touch)
    Multimedia Core → Audio Amplifier (to Speaker)
    Integrated Antenna (LTE) ↔ Mobile Communication (2G, 3G, 4G) ↔ Multimedia Core ← Switch Detect Circuit ← Control Button

    放大此图片
  2. IVI, HUD, Head Up Display

    LV Battery → LV Power Supply → Low Voltage
    ↔ User Interface & Communication ↔ MCU
    MCU → LED Driver → LED Backlight → LCD Panel Module → Mirror → Wind Shield or Combiner
    MCU → Graphic Controller → RGB/LVDS → LCD Panel Module → Mirror → Wind Shield or Combiner
    MCU → Motor Driver (Stepper) → M
    MCU → Motor Driver (DC) → Open/Close Operation → Combiner

    放大此图片
  3. IVI, TCU, Telematics Control Unit

    LV Battery → LV Power Supply → Low Voltage
    ↔ User Interface & Communication ↔ AP ← Audio codec - Microphone
    AP → Audio Amp. - Speaker
    AP ↔ WiFi/BT
    AP ↔ GNSS
    AP ↔ Modem(Baseband Processor) ↔ RF Transceiver [RF IC(LTE/3G), FEM, 5G, C-V2X]
    AP ↔ Memory

    放大此图片

Body · Chassis

  1. Body·Chassis, LED Lighting with AFLS

    LV Battery → AFLS(Stepper Motor Driver & Current Limit, Up & Down, Left & Right)
    LV Battery → LV Power Supply → Low Voltage
    LV Battery → LV Power Supply → MCU ↔ AFLS(Stepper Motor Driver & Current Limit, Up & Down, Left & Right)
    ↔ User Interface & Communication ↔ MCU → Cooling Fan Driver, LV Bat. → LED, Fan
    ↔ User Interface & Communication ↔ MCU → Led Driver, LV Bat. → Head Lamp(High Beam, Position Light, Low Beam, Turn Light, DRL, Fog Light)
    ↔ User Interface & Communication ↔ MCU → Led Driver, LV Bat. → Rear Lamp(Tail Light, Reverse Light, Stop Light, Turn Light)

    放大此图片
  2. Body·Chassis, EPS Electric Power Steering

    LV Battery → LV Power Supply → Low Voltage
    LV Battery → 3-Phase Inverter (M)
    LV Battery → Gate Driver → 3-Phase Inverter (M)
    ↔ User Interface & Communication ↔ SBC & MCU → Gate Driver → 3-Phase Inverter (M) → Phase Current/Voltage, Resolver → Sense& Monitor → SBC & MCU

    放大此图片
  3. Body·Chassis, BAU, Brake Actuation Unit

    LV Battery → Pump Driver & Switch , MCU - Pump(m)
    LV Battery → LV Power Supply → Low Voltage
    LV Battery → LV Power Supply → Oli Pressure, Wheel Speed, Brake Pedal, Yaw Rate, Brake-Light Control, Engine/Transmission Torque Request ↔ Sensor Interface & Communication ↔ MCU
    LV Battery → System Basic Chip ↔ MCU
    LV Battery → System Basic Chip → Safety Driver & High-Side Switch → Solenoid, Solenoid, Solenoid → Solenoid Driver & Low-Side Switch ↔ MCU

    放大此图片

EV

  1. EV, OBC, On Board Charger

    85V to 256Vac - Full Bridge LLC Converter x 2Block circuit diagram - 200V to 400Vdc
    ----- Isolation -------Isolated Gate Driver → Full Bridge LLC Converter x 2Block circuit diagram
    ↔ User Interface & Communication ↔ MCU → Isolated Gate Driver
    LV Battery → LV Power Supply → MCU
    MCU ← Sense & Monitor ← Current / Voltage ← 200V to 400Vdc
    Sense & Monitor ← Power Supply → Isolated Gate Driver → Full Bridge LLC Converter x 2Block circuit diagram

    放大此图片
  2. EV, BMS Battery Management System

    HV Battery (+) - Cell Module ···Cell Module - HV Battery (-)
    Volt. → Cell Module Control Unit [ Cell Balancing & Fault monitoring ↔ MCU(Slave#1) ↔ Isolator ---- Isolation] ↔ CAN ↔ MCU (Master) ↔ User Interface & Communication ↔ Temp. → Cell Module Control Unit [ Cell Balancing & Fault monitoring ↔ MCU(Slave#1) ↔ Isolator ---- Isolation] ↔ CAN ↔ MCU (Master) ↔ User Interface & Communication ↔ HV Battery (+)(-) → HV Sensing → MCU (Master) ← LV Power Supply → User Interface & Communication ↔ LV Battery → LV Power Supply

    放大此图片
  3. EV, Inverter, Main Motor Driver

    LV Battery → LV Power Supply → User Interface & Communication
    LV Battery → LV Power Supply → MCU
    ↔ User Interface & Communication ↔ MCU → Isolated Gate Driver → IGBT Module - M
    ↔ User Interface & Communication ↔ MCU ← Sense & Monitor
    IGBT Module → Temperature → Sense & Monitor
    Between IGBT Module and M → Phase Current / Voltage → Sense & Monitor
    M → Resolver / Temperature → Sense & Monitor
    Isolation --- Isolated Gate Driver --- Power Supply --- Sense & Monitor ---
    DC-Link Capacitor ← HV Battery

    放大此图片

Product Search

Normal(All Location)
X7* Normal(Epoxy)
C0G Normal
PN Series
ESD Strengthen (Connector I/F)
ESD Strengthen
PE Series
High Temperature
(Near Power Semiconductor)
X8* Normal
PN Series
Crack Mitigation
(12V Battery Line, Near Hole & Connector)
Soft Termination(*PJ Series)
Fail Safe/Soft Term.(XPJ Series)
*PJ Series / XPJ Series

产品特点

  • 拥有可靠性提升的
    Soft Termination 技术
  • 防止短路的坚固设计
  • 具有很高有效容
    量的优越的电特性

Driving Assistance & Safety

面向人类的三星电机引领相机模块、无人驾驶的安全变化。

三星电机截至目前共提供10亿个相机模块,在相机技术领域处于国际领先地位。在汽车领域,过去10多年间与 OEM 及 Tier 1 客户合作,发展显著。在模块设计、封装、生产领域,凭借三星电机特有的优势,使客户能够确保足够强的竞争力。

Viewing Camera
Viewing Camera
三星电机的车载用相机支持VGA、HD、Full HD版本,按照所有种类的汽车应用程序,设计适合的产品。该相机根据汽车规格进行测试,按照顾客想要的样式,发挥最佳性能。
  • Surround View
  • Rear View
  • Park Assist
  • Mirror Replacement
Sensing Camera
Sensing Camera
三星电机遥感相机将准确的机器视觉最优化,提供延伸的感知性能。而且从相机和 ECU 罩内部散热的功能十分突出。三星电机与多家图像传感器企业合作,提供柔性形态选择。
  • Automatic Emergency Braking
  • Lane Departure Warning
  • Forward Collision Warning
  • Adaptive Cruise Control Traffic Sign Recognition
  • Blind Spot Detection
Interior Camera
Interior Camera
三星电机的内部装饰摄像机提供卓越的光学性能,使用甚至肉眼很难注意到的微型形态,能够应用于多类汽车应用程序。同时凭借惊艳的内部光学设计力量,考虑到不同国家驾驶座相异的位置及驾驶人员体格等环境因素,提供满足多种应用程序的相机。
  • Driver Monitoring
  • Passenger Identification
  • Video Conferencing

产品特点

  • 拥有自主镜头技术最优化针对型设计
  • 优秀的夜间性能
  • 微型形态
  • 高可靠性温度、震动、水分
  • 高分辨率延伸的感知性能
  • 低弯曲镜头设计

Seamless Connectivity

三星电机的车载用 WiFi Module,实现车辆内顺畅的通信环境。

三星电机为给用户提供顺畅的通信环境,在无线通信中结合公司自主的技术专业性,开发高性能汽车元件。

WiFi Module
WiFi Module
三星电机生产智能手机用WiFi/Bluetooth等最高水平的通信模块。三星电机的汽车模块支持低噪设计的最优化稳定 RF 性能。凭借关于智能手机/IT产品的专业性和高水平封装技术,可提供小型形态产品。
  • Infotainment Head Unit
  • Smartphone Tethering
  • WiFi Hotspot (in-vehicle)

产品特点

  • 高级封装技术超小型形态
  • 低噪设计最优化、安全的 RF 性能
  • 最优化的 BT/WiFi
    运营软件
