技术 - Article 2024.11.20

Application Guide > Automotive > ADAS LiDAR

通过小型化开发， LiDAR从原来体积较大形态下的机械式，发展到可以内置在车辆的前部、保险杠、格栅边。



根据LiDAR传感器的小型化趋势，三星电机持续扩大小型高容值车规MLCC Line-up及供应。




MLCC 趋势  : 小型化, 高精度

▷ 小尺寸 & 高容值High-Capacitance

▷ 高可靠性

 → 推荐方案 :  X7* PN系列



Size

(inch/mm)

Rated Voltage

[Vdc]

TCC

Capacitance

Part Number

MP

Status

Sample

Availability

0402/1005

10

X7S

2.2㎌

CL05Y225KP66PN#

NEW

Available

0603/1608

10

X7S

4.7㎌

 CL10Y475KP96PN#

In MP

Available

0805/2012

10

X7R

10㎌

 CL21B106KPY6PN#

In MP

Available

1206/3216

10

X7R

22㎌

CL31B226KPK6PN#

In MP

Available

1210/3225

10

X7S

47㎌

CL32Y476KPVVPN#

In MP

​Available
