ニュース

2025.01.15

サムスン電機、車載用MLCC 2012mm C0G 2200pF 630V 発売

▷ 2.0×1.25mm(0805 inch)サイズ、C0G(-55 to 125℃)、定格電圧630Vで静電容量2200pFを実現するCL21C222JHY3PN#製品を開発し量産を開始しました。 サンプルの提供も可能です。



▷ 電気自動車のX-in-1 パワートレインの開発に伴うOBC、インバータ、DC-DCコンバータ、無線充電(WPT)、バッテリー管理システム(BMS)、コンプレッサー、ポンプなど、車載システムの統合トレンドで、パワートレインに採用される部品の高集積·高密度·小型化のニーズが増加しています。



▷ 今回のMLCC新製品は、従来の3.2x1.6mm(1206 inch)製品と同一の容量・定格電圧を保ちながら2.0×1.25mm(0805 inch)にサイズを縮小させることで、該当アプリケーションの小型・高容量設計、高温(125℃)および電圧の安定性というニーズを同時に満たします。



▷ サムスン電機は独自のセラミックおよび電極材料の微粒化と超精密積層工法を適用し、2.0×1.25mm(0805 inch)サイズ、定格電圧630V、2200pFまで製品のカバー領域を拡大しました。




Samsung

Size

(mm/inch)

Capacitance

Rated Voltage

TCC

CL21C222JHY3PN#

2012/0805

2200pF

630Vdc

C0G

(C0G : -55℃~125℃ における容量変化率 : 0±30ppm/℃)

 ​

Frequency Characteristics
